Features:
∙Flexible and conformable
∙Good adhesion and easy to peel, leaving no residue
∙High temperature resistance up to 200℃
∙Excellent electrical insulation
Application:
∙ Mask or binding for high temperature coating protection in home appliances, machinery, electronics and other industries
∙ Mask or binding for high temperature coating insulation protection in electronic products and automotive industry
∙ Joint use of release paper (also known as: feeder tape)
Product series and main technical parameters:
Product Number
HZTAPE-
HZTAPE-
HZTAPE-
HZTAPE-
HZTAPE-
HZTAPE-
HZTAPE-
Backing/Adhesive
PET/Silicone
PET/Silicone
PET/Silicone
PET/Silicone
PET/Silicone
PET/Silicone
PET/Silicone
Backing thickness ( mm)
0.025
0.028
0.035
0.035
0.038
0.05
0.075
Total thickness (mm)
0.04
0.055
0.05
0.06
0.065
0.08
0.13
Adhesion to steel(N/25mm)
3.0-4.0
6.5-7.5
4.0-5.0
6.0-7.0
6.0-7.0
6.0-7.0
13-14
Tensile strength(Kg/25mm)
11
13
15
15
16
22
36
Elongation%
120-130
120-130
120-130
120-130
120-130
100-110
140-145
Dielectric strength (Volt)
8,200
8200
7,000
7000
6300
4200
3,500
Temp. rating (℃)
-40℃-200℃
-40℃-200℃
-40℃-200℃
-40℃-200℃
-40℃-200℃
-40℃-200℃
-40℃-200℃
Color
Clear / Red / Green / Yellow / Blue / Black Blue /
Black /Opal
P2540
P2855
P3550
P3565
P3865
P5080
P7513
Slitting and packing :
1. Width：500mm, 1020mm, 1050mm, 2-1000mm
can be customized slitting
2. Length: 33m, 66m, 220m, can be customized
3. Plastic core internal diameter：76mm(3”), 38mm(1.5”)
4. Packing: carton or pallet
Note： Above data is the accumulative value by using the recognized test methods. In order to ensure the correct selection of the products, please refer the specification and test sample, or feel free to contact our technical service to provide you with further services.
